D28 3D WELDING TABLE
FIXTO D28 Series Welding Tables are made for the most Heavy-Duty Metal Fabrication Fixturing Applications. They truly are built to last a lifetime and beyond. The FIXTO, Indian-Engineered Welding Tables are extremely rigid and have the flattest surface of any Welding Table in the market, with a option of 5-Sided 3D and 1- Sided 2D welding tables which can be used with or without optional heavily constructed legs. The Nitride finish protects the welding table against rust and weld spatter to make sure that the Welding Tables surface is kept extremely clean and accurate for fixturing.
Features:
- D28 Hole separation=100±0.05mm
- Stiffener base to ensure stability
- Have 5 working surfaces
- Surface hardness=20HRC
- Flatness=0.3/1000mm
- Verticality=0.1/200mm
- Surface Roughtness=Ra3.2
Models
| Add to My Fixture | MODEL NO | LENGTH | WIDTH | HEIGHT | |
|---|---|---|---|---|---|
| NPG-1010 | 1000 | 1000 | 750/900 | Click to view | |
| NPG-1212 | 1200 | 1200 | 750/900 | Click to view | |
| NPG-1510 | 1000 | 1000 | 750/900 | Click to view | |
| NPG-2010 | 2000 | 1000 | 750/900 | Click to view | |
| NPG-2015 | 2000 | 1500 | 750/900 | Click to view | |
| NPG-1224 | 1200 | 2400 | 750/900 | Click to view | |
| NPG-3015 | 3000 | 1500 | 750/900 | Click to view |
